GrandAire WJH524000K000B 2 Ton 13.4 SEER2 Heat Pump Package Unit, 208-230/1/60, R-454B, Single Stage
Write a Review
Write a Review
GrandAire
GrandAire WJH524000K000B 2 Ton 13.4 SEER2 Heat Pump Package Unit, 208-230/1/60, R-454B, Single Stage
- MPN:
- WJH524000K000B
- Brand:
- GrandAire
- Availability:
- 2 In Stock
$2,999.95
Product Details
Features and Specifications
| Weight | 312 |
|---|---|
| AHRI - Usage | Packaged |
| Air Flow Direction | Horizontal |
| Blower Motor HP | 1/3 |
| Blower Motor Speeds | Multiple |
| Blower Motor Type | ECM (Electronically Commutated Motor) |
| Brand | GrandAire |
| CBU - Compressor Bearing Unit | Yes |
| Condenser Motor HP | 1/8 |
| Condenser Motor RPM | 825 |
| Condenser Motor Type | PSC (Permanent Split Capacitor) |
| Cooling Capacity | 24,000 |
| COP | 2.2-3.7 |
| Cycle/Hertz | 60 Hz |
| Drive Type | Direct |
| EER2 | 11.05 |
| Energy Star Rated | No |
| Equipment Type | Heat Pump |
| Evaporator Coil Metering Device | Piston |
| Heating Capacity | 12,300-23,000 |
| Height | 30.13 |
| HSPF2 | 6.7 |
| Length | 51 |
| Locked Rotor Amps (LRA) | 63 |
| OPT Code | 1PWJH524000K000B |
| Phase | Single |
| Product Family | WJH5 |
| Prop 65 | Yes |
| Refrigerant | R-454B |
| SEER2 | 13.4 |
| Sound Level (dBA) | 70 |
| Tonnage | 2 |
| UOM | EA |
| UPC | See Optical |
| Voltage | 208-230 VAC |
| Width | 32 |
| Maximum Overcurrent Protection (MOCP) | 70 |
| Condenser Coil Fins per Inch (FPI) | 20 |
| Evaporator Coil Fins per Inch (FPI) | 12 |
| Compressor Type | Scroll |
| Country of Origin | MEX |
| Blower Wheel Diameter | 11" |
| Blower Wheel Width | 8" |
| Substantial Commodity | Steel; Copper; Aluminum |
| Condenser Fan Blade Diameter | 20 |
| Condenser Fan Motor Qty | 1 |
| Condenser Coil Metering Device | Piston |
| Return Air Filter Size (RA) in Inches (W x H x D) | 20 x 20 x 1 |
